Claros API — Developer Reference

Overview

ClarosAPI provides server-to-server access to Claros's actuarial rating engine. Submit a health plan scenario as XML and receive calculated stop-loss rates, PEPM figures, and underwriting summaries — delivered asynchronously via a polling model.

All requests are routed through Azure API Management. Every call requires two credentials issued by Claros: a clientId and an Ocp-Apim-Subscription-Key.

Base URL https://claros-client-connect-api-management-service.azure-api.net

Prerequisites

Before making any API calls, Claros must provision your account. You will receive:

clientId A UUID identifying your application. Provided by Claros.

Ocp-Apim-Subscription-Key A 32-character hex key for APIM gateway access. Provided by Claros.

Keep credentials secure Never expose your clientId or subscription key in client-side code, source control, or logs. Store them in a secrets manager or environment variables.

Quick Start

Three calls to get a completed rate report:

STEP 01

Get Access Token

POST your clientId to /Auth. Receive a Bearer token valid for one hour.

→

STEP 02

Submit a Report Request

POST your scenario XML to /v1/Report. Receive a jobId GUID.

→

STEP 03

Poll for Result

GET /v1/Report?jobid=… until status is Completed. The body is your result XML.

API Reference

Get Access Token

Exchange your clientId for an OAuth 2.0 access token. Include this token as a Bearer credential on all subsequent requests.

POST https://claros-client-connect-api-management-service.azure-api.net/Auth

Request Headers

Header	Type	Required	Description
Ocp-Apim-Subscription-Key	string	Required	Your APIM subscription key, provided by Claros.
Content-Type	string	Required	`application/json`

Request Body

Field	Type	Required	Description
clientId	string (UUID)	Required	Your application client ID, provided by Claros.

HTTP

POST /Auth HTTP/1.1
Host: claros-client-connect-api-management-service.azure-api.net
Content-Type: application/json
Ocp-Apim-Subscription-Key: {your-subscription-key}

{
  "clientId": "{your-client-id}"
}

Response

200 OK

{
  "access_token": "eyJ0eXAiOiJKV1QiLCJhbGciOiJSUzI1NiIs..."
}

401 Unauthorized

{
  "error": "Invalid Client Credentials"
}

Token lifetime Access tokens are valid for 60 minutes. Cache the token and refresh it before expiry.

Submit a Report Request

Submit an XML scenario payload for asynchronous processing. Returns a jobId you use to poll for the result.

POST https://claros-client-connect-api-management-service.azure-api.net/v1/Report?reportname={reportname}

Request Headers

Header	Type	Required	Description
Authorization	string	Required	`Bearer {access_token}` — from Get Token.
Ocp-Apim-Subscription-Key	string	Required	Your APIM subscription key, provided by Claros.
Content-Type	string	Required	`application/xml` or `text/xml`

Query Parameters

Parameter	Type	Required	Description
reportname	string	Required	The report type to generate. See Report Types. Case-insensitive.

Request Body

Raw XML conforming to the Claros plan schema. Maximum size: 1 MB. See Request Format.

HTTP

POST /v1/Report?reportname=RATEREPORT HTTP/1.1
Host: claros-client-connect-api-management-service.azure-api.net
Authorization: Bearer {access_token}
Content-Type: application/xml
Ocp-Apim-Subscription-Key: {your-subscription-key}

<?xml version="1.0" encoding="utf-16"?>
<Scenarios TotalPlans="1" DataYear="2024" ScenariosId="2623773">
  <Scenario ScenarioId="2623111" ScenarioName="Plan A" TrendDate="2026-01-01">
    ...
  </Scenario>
</Scenarios>

Response

The response body is the jobId — a UUID string. Store it to poll for the result.

200 OK

"533555c4-2cf5-4b9b-848d-57742d5b76a7"

XML validation responses Schema validation errors return 200 OK with a plain-text error message in the body — not an HTTP error code. Check for non-XML content before parsing the response.

Get Report Status / Result

Poll this endpoint after submitting a report. When status is Completed, the response body contains the result XML.

GET https://claros-client-connect-api-management-service.azure-api.net/v1/Report?jobid={jobId}

Request Headers

Header	Type	Required	Description
Authorization	string	Required	`Bearer {access_token}`
Ocp-Apim-Subscription-Key	string	Required	Your APIM subscription key, provided by Claros.

Query Parameters

Parameter	Type	Required	Description
jobid	string (UUID)	Required	The job ID returned from Submit a Report Request.

HTTP

GET /v1/Report?jobid=533555c4-2cf5-4b9b-848d-57742d5b76a7 HTTP/1.1
Host: claros-client-connect-api-management-service.azure-api.net
Authorization: Bearer {access_token}
Ocp-Apim-Subscription-Key: {your-subscription-key}

Responses by Job Status

Pending or Processing

{
  "jobId": "533555c4-2cf5-4b9b-848d-57742d5b76a7",
  "status": "Pending",
  "message": "Job is still being processed. Please poll again."
}

Completed — result XML

<ClarosRateResults>
  <Scenario>
    <ScenarioId>2623111</ScenarioId>
    <FirstDollarRates>...</FirstDollarRates>
    <RateTable>...</RateTable>
    <StopLossAggRates>...</StopLossAggRates>
    <StopLossSummaries>...</StopLossSummaries>
  </Scenario>
</ClarosRateResults>

Failed

{
  "jobId": "533555c4-2cf5-4b9b-848d-57742d5b76a7",
  "status": "Failed",
  "error": "Something Went Wrong Please Try Again"
}

Reference

Request Format (XML)

The request body must be a valid XML document conforming to the Claros plan schema. The root element is <Scenarios>.

Root Element Attributes

Attribute	Type	Description
TotalPlans	integer	Number of plans in the submission.
DataYear	integer	Data year for the rating analysis (e.g. `2024`).
ScenariosId	integer	Unique identifier for this scenario group.

Scenario Child Elements

Element	Description
Population	Census data: enrollment tiers, ZIP codes, employee counts, and tier ratios.
StopLoss	Stop-loss configuration: specific deductible, aggregate settings, reimbursement percentages, incurred/paid periods, and expense loads.
Networks	Network definitions with medical discount rates by category (IP, OP, Rx, and subcategories).
Plan	Benefit plan design including deductibles, copays, co-insurance, and MOOP per medical grouping and subplan.

XML — Example Request Payload

<?xml version="1.0" encoding="utf-16"?>
<Scenarios TotalPlans="1" DataYear="2024" ScenariosId="2623773"
           PlanYearEnabled="false" NormalizationEnabled="false">

  <Scenario ScenarioId="2623111" ScenarioName="Plan A"
            TrendDate="2026-01-01" HealthStatus="1.0"
            UseInducedDemand="N" UseGeoHealth="N">

    <Population PopulationId="1" CensusType="1" Industry="0"
                EnrollmentTiers="4" T1Ratio="1.00" T2Ratio="2.20"
                T4Ratio="1.80" T5Ratio="3.00">
      <EmployeesInZip>
        <Zip Zip3Code="606" EnrolledEmp="579" />
      </EmployeesInZip>
    </Population>

    <StopLoss OptionNo="2"
              SpIsMedical="Y" SpIsRx="Y"
              SpDeductible="50000"
              SpIncurred="12" SpPaid="24"
              SpIsUnlimitedCoverage="Y" SpReimbPercent="1"
              AgIsMedical="Y" AgIsRx="Y"
              AgIncurred="12" AgPaid="24"
              AgReimbPercent="1"
              AgMargin="125" AgSpecCorridor="0"
              OptionName="Standard" />

    <Networks>
      <Network NetworkId="1000" NetworkName="In Network">
        <Discounts MedicalGrouping="GBL"
                   DiscountAmount="0.477"
                   DiscountOrPercentMedicare="D"
                   MedicalCompositeDiscount="47.7" />
      </Network>
      <Network NetworkId="3000" NetworkName="Out of Network">
        <Discounts MedicalGrouping="GBL"
                   DiscountAmount="0.1"
                   DiscountOrPercentMedicare="D"
                   MedicalCompositeDiscount="10.0" />
      </Network>
    </Networks>

    <Plan PlanNo="1" PlanName="Standard Plan">
      <SubPlan SubPlanId="1" NetworkId="1000" InOutRxNetwork="I">
        <!-- PlanElement entries per medical grouping (IP, OP, RAD, LP, PH, O, Rx) -->
      </SubPlan>
    </Plan>

  </Scenario>
</Scenarios>

Schema validation Payloads are validated against clarosplan-schema-definition.xsd (version 1.0.0). Download it from Schema & Changelog.

Reference

Schema & Changelog

The request XSD is served by the API. It is the same file the API uses to validate /v1/Report requests, so it is always current.

Resource	Endpoint	Current version
Request schema (XSD)	`GET /v1/Schema/request`	1.0.0
Changelog	`GET /v1/Schema/changelog`	—

Both endpoints require your Ocp-Apim-Subscription-Key header. No access token is needed.

cURL — Download the request schema

curl -o clarosplan-schema-definition-v1.xsd \
  -H "Ocp-Apim-Subscription-Key: {subscription_key}" \
  https://claros-client-connect-api-management-service.azure-api.net/v1/Schema/request

The version is also in the file itself: <xs:schema ... version="1.0.0">.

Versioning rules

Change	Version	Impact on your requests
Fix or loosen a rule, add an optional field	Minor (1.0.0 → 1.1.0)	None. Existing requests stay valid.
Remove or rename a field, make a field required, change a type	Major (2.0.0)	Published under new `/v2` routes. `/v1` keeps working unchanged.

Changelog

Version	Date	Changes
1.0.0	2026-10-06	First versioned release; replaces the unversioned September 2025 schema. All changes are non-breaking. Fixed `PlanElement@Copay1Perc`: decimal → string (accepts values such as `d.0`) `StopLoss` can repeat (multiple stop-loss options) Now accepted as optional attributes: `TrendDetails@UserTrend` `PlanElement@IsCoveredForMe`, `@IPDayAdmit`, `@ServiceLimit` `Deductible@Deductible2PlanPaysPerc`, `@MECPlan` Zip3 row: `@TableIndex`, `@RowIndex` Utilization row and Rx plan element: `@IPDayAdmit`, `@ServiceLimit`

Response Format (XML)

When a job reaches Completed status, the response body is a <ClarosRateResults> XML document containing actuarial output for each submitted scenario.

Output Sections

Element	Description
FirstDollarRates	Per-tier first-dollar PEPM rates before stop-loss adjustment. Tiers: `EE`, `EE+SP`, `EE+CH(s)`, `EE+Family`, `TOTAL`.
FirstDollarSummaries	Factor-by-factor development of first-dollar rates: trend, area, network discount, age/gender, industry, utilization, and benefit design — for Medical, Rx, and combined.
RateTable	Net premium rates per tier after all underwriting adjustments.
StopLossAggRates	Aggregate stop-loss PEPM rates per tier.
StopLossAggRateAtts	Aggregate rates at the attachment point per tier.
StopLossSummaries	Detailed stop-loss development: LT/GT claim costs, area/network/age factors, aggregate attachment, and expense loads — split by Medical (M), Rx (R), and Total (T).

XML — Completed Result (abbreviated)

<ClarosRateResults>
  <Scenario>
    <ScenarioId>2623111</ScenarioId>

    <FirstDollarRates>
      <FirstDollarRate>
        <OptionNo>2</OptionNo>
        <TierNo>1</TierNo>
        <TierDesc>EE</TierDesc>
        <CountOfEmployees>289.50</CountOfEmployees>
        <RatePEPM>559.8327</RatePEPM>
      </FirstDollarRate>
      <FirstDollarRate>
        <TierNo>2</TierNo>
        <TierDesc>EE+SP</TierDesc>
        <CountOfEmployees>86.34</CountOfEmployees>
        <RatePEPM>1231.6318</RatePEPM>
      </FirstDollarRate>
      <!-- Additional tiers: EE+CH(s), EE+Family, TOTAL -->
    </FirstDollarRates>

    <RateTable>
      <RateTable>
        <TierDesc>EE</TierDesc>
        <CountOfEmployees>289.50</CountOfEmployees>
        <RatePEPM>119.3380</RatePEPM>
      </RateTable>
      <!-- Additional tiers -->
    </RateTable>

    <StopLossAggRates>...</StopLossAggRates>
    <StopLossAggRateAtts>...</StopLossAggRateAtts>
    <StopLossSummaries>...</StopLossSummaries>

  </Scenario>
</ClarosRateResults>

Report Types

Access to each report type is controlled by roles assigned to your account. Submitting a report your account is not authorized for returns 403 Forbidden.

RATEREPORT

Actuarial stop-loss rate calculation. Produces first-dollar PEPM rates, aggregate and specific stop-loss premiums, and underwriting factor summaries by enrollment tier.

Required role: access-to-rate-report

Case-insensitive The reportname parameter is normalized to uppercase internally. ratereport, RateReport, and RATEREPORT are all valid.

Job Lifecycle

Report processing is asynchronous. A job progresses through the following states:

Pending

Job has been queued and is awaiting pickup by the worker service.

Processing

Worker is actively running the actuarial calculations.

Completed

Calculations finished. The response body is the full result XML.

Failed

An error occurred during processing. Resubmit or contact Claros support.

Recommended Polling Strategy

Use exponential backoff — start at 5 seconds, doubling up to a 60-second ceiling:

Pseudocode

interval = 5s
maxInterval = 60s

while true:
    response = GET /v1/Report?jobid={jobId}

    if response.status == "Completed":
        return response.body   // result XML

    if response.status == "Failed":
        throw Error(response.error)

    wait(interval)
    interval = min(interval * 2, maxInterval)

Rate Limits

Each subscription key is limited to 5 requests per second. Exceed that and the gateway rejects the call immediately with a 429 — no request reaches the API.

5

Requests / second

Per subscription key. Requests above this threshold are rejected immediately.

429

Status on exceed

Too Many Requests. The gateway drops the call and returns this status immediately.

2s

Retry-After

Minimum wait before retrying. Sent as a response header on every 429 response.

429 Response

When the rate limit is exceeded, the gateway returns the following response. Do not retry until the Retry-After interval has elapsed.

429 Too Many Requests

HTTP/1.1 429 Too Many Requests
Retry-After: 2
Content-Type: application/json

{
  "statusCode": 429,
  "message": "Rate limit is exceeded. Try again after 2 seconds."
}

Handling 429 in Your Client

Pseudocode

MAX_RETRIES = 3
retries = 0

while retries < MAX_RETRIES:
    response = POST /v1/Report?reportname=RATEREPORT

    if response.status == 429:
        retryAfter = response.headers["Retry-After"] ?? 1
        wait(retryAfter * (2 ** retries))   // exponential backoff
        retries += 1
        continue

    if response.status == 200:
        return response.body   // jobId

    throw Error("Unexpected status: " + response.status)

Design for the limit, not around it If your integration is regularly hitting 429 responses, the root cause is typically unbounded parallelism — submitting all scenarios simultaneously rather than in a controlled queue. Throttle submissions on the client side to stay comfortably under 5 requests per second. Contact your Claros account team if a higher limit is required for your use case.

Error Handling

200 OK Request succeeded. Note: XML validation failures also return 200 with plain-text error in the body.

400 Bad Request Missing required parameters, invalid jobId format, or empty request body.

401 Unauthorized Invalid or expired access token, invalid clientId, or missing Ocp-Apim-Subscription-Key.

403 Forbidden Your account does not have the required role for the requested report type.

404 Not Found The jobId does not exist or does not belong to your account.

429 Too Many Requests Gateway rate limit exceeded (5 req/sec per subscription). Wait at least 2 seconds before retrying. See Rate Limits.

500 Internal Server Error Unexpected server error. Contact Claros support with the request timestamp.

APIM Gateway: Missing Subscription Key

401 — APIM

{
  "statusCode": 401,
  "message": "Access denied due to missing subscription key. Make sure to
              include subscription key when making requests to an API."
}

Claros Client Connect API · v1.0 · For credentials or support, contact your Claros account team.
